380V Electric Chain Hoist: Precision Lifting for Industrial Operations
The 380V Electric Chain Hoist is a robust and reliable solution designed for construction, warehouses, and demanding industrial tasks. Engineered with a high-performance pure copper motor, this 380V Electric Chain Hoist delivers consistent power and long-term durability for heavy-duty lifting. As a premier lifting equipment supplier , CloudHub ensures that every hoist meets international safety standards with precision engineering.
Superior Build Quality and Safety Features
Our 380V Electric Chain Hoist stands out due to its premium components designed for maximum security:
Pure Copper Motor: Provides high efficiency and heat resistance for continuous operation.
Alloy Steel Housing: Durable yet lightweight, protecting the internal gears of the 380V Electric Chain Hoist from impacts.
Automatic Brake System: The power-off automatic brake ensures that the load is held securely, preventing accidents during power failures.
Manganese Steel Chain: Features high-tensile G80 chains that offer superior wear resistance compared to standard materials.
Synthetic Durability: For delicate loads, this hoist pairs perfectly with high-strength polyester slings to prevent surface scratches.
Technical Specifications & Customization
We understand that every project has unique needs, which is why our 380V Electric Chain Hoist is fully customizable. We offer various capacities ranging from 0.5 ton up to 5 tons, with lifting speeds optimized for each model (from 2.7 m/min to 6.8 m/min). Whether you need a single-speed or dual-speed configuration, our 380V Electric Chain Hoist can be tailored to your requirements, including custom colors like blue, yellow, or orange. This flexibility makes us a top choice for wholesale lifting equipment .
Key Performance Data
Capacity Range: 0.5t / 1t / 1.5t / 2t / 2.5t / 5t
Standard Lifting Height: 3 meters (customizable)
Voltage Compatibility: Designed for 3-phase 200V~460V (50/60Hz) systems.
Test Load: Rigorously tested up to 1.25 times the rated capacity (e.g., 6.25T for the 5T model).
Partner with CloudHub for Your Next Project
Investing in a high-quality 380V Electric Chain Hoist significantly improves workplace efficiency and safety. At CloudHub, we manage the entire supply chain to provide you with the most competitive wholesale lifting equipment prices without compromising on quality.
Ready for a detailed quote? Please visit our lifting equipment inquiry page and submit your technical requirements. Our expert team will provide a customized solution within 24 hours.
Features:
1.Pure copper motor
2.Alloy steel housing
3.Power off automatic brake
4.Manganese steel chain
5.Anti-stripping steel hook
6.Single speed or dual speed as your required.
7.Color can be made as your required : blue , yellow , orange , red , etc.
The special specification could be customized according to customer requirements.
Electric hoist can be used for construction, household, warehouse and other operations.
| Capacity(t) | 0.5 | 1 | 1.5 | 2 | 2.5 | 5 | |
| Standard Lifting Height(m) | 3 | ||||||
| Lifting Speed(m) | 6.8 | 6.6 | 8.8 | 6.6 | 5.4 | 2.7 | |
| Lifting Motor | Power(kw) | 0.75 | 1.5 | 3 | 3 | 3 | 3 |
| Rotation Speed(r/min) | 1440 | ||||||
| Phases | 3 | ||||||
| Lifting Voltage(v) | 200~460 | ||||||
| Lifting Frequency(Hz) | 50/60 | ||||||
| Chain Turns | 1 | ||||||
| Chain Specification | 6.3 | 7.1 | 10 | 10 | 11.2 | 11.2 | |
| Test Load(T) | 0.625 | 1.25 | 1.875 | 2.5 | 3.125 | 6.25 | |
| Weight(kg) | 47 | 61 | 108 | 115 | 116 | 151 | |
| Weight Added with 1m Higher(kg) | 0.81 | 1.1 | 2.3 | 2.3 | 2.8 | 5.6 | |
